Description
| Model |
DHX-130 |
DPR20013B |
| Max. Drilling capacity (mm) |
13 |
13 |
| Diameter of column (mm) |
46 |
46 |
| Spindle travel (mm) |
50 |
50 |
| Distance spindle axis to column generating line (mm) |
103 |
103 |
| Max. Distance spindle nose to table (mm) |
220 |
220 |
| Max. Distance spindle nose to base (mm) |
300 |
300 |
| Spindle taper |
B16 |
B16 |
| Spindle speeds range (r/min) |
515-2580 |
515-2580 |
| Spindle speeds series |
5 |
5 |
| Dimension of worktable surface (mm) |
160 X 160 |
160 X 160 |
| Dimension of base (mm) |
280 X 180 |
280 X 180 |
| Overall height (mm) |
580 |
580 |
| Motor (KW) |
1.25/1.8 |
1.25 |
| G.W/N.W (kg) |
21/19 |
19/17 |
| Packing dimension (cm) |
46 X 33 X 23 |
78 X 46 X 29 |
